Keithley 2002 User Manual

IEEE-488 Reference
3-119
Bit B14, Command Warning (Warn) — Set bit indicates that a Signal Oriented Measurement
Command parameter has been ignored (PTR), or a subsequent Signal Oriented Measurement
Command has executed successfully (NTR).
Note: Whenever a questionable event occurs, the ERR annunciator will turn on. The annunciator
will turn off when the questionable event clears.
Operation Event Register:
Bit B0, Calibrating (Cal) — Set bit indicates that the instrument is calibrating (PTR), or cali-
bration is complete (NTR).
Bits B1, B2 and B3 — Not used.
Bits B4 Measuring (Meas) — Set bit indicates that the instrument is actively measuring (PTR),
or the measurement has finished.
Bit B5, Waiting for Trigger (Trig) — Set bit indicates that the instrument is waiting in the trig-
ger layer (PTR) of the trigger model, or that it has left the trigger layer (NTR).
Bit B6, Waiting for Arm (Arm) — Set bit indicates that the instrument is waiting in an arm
layer of the trigger model (PTR), or operation has proceeded from the arm layers into the trigger
layer (NTR).
Bits B7, B8 and B9 — Not used.
Bit B10, Idle — Set bit indicates that the instrument is in the idle state (PTR), or has left the
idle state to perform an operation (NTR).
Bits B11 through B15 — Not used.
Cal
B13 - B9 B8B15 B14
(2 )
8
256
(2 )
14
16384
0/10/1
Warn
B7 - B5
0
Temp
B4
(2 )
4
16
0/1
B3 - B0
Bit Position
Event
Decimal Weighting
Value
Events : Warn = Command Warning
Cal = Calibration Summary
Temp = Temperature Summary
Value : 1 = Questionable Event Bit Set
0 = Questionable Event Bit Cleared
Figure 3-22
Questionable Event Register

Keithley 2002 Specifications

General

Resolution	8.5 digits
DC Voltage Accuracy	±0.0006%
Maximum DC Voltage	1000 V
Maximum AC Voltage	750 V
Maximum DC Current	3 A
Maximum AC Current	3 A
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Resistance Range	10 Ω to 1 GΩ
Model	2002
Category	Multimeter
Interface	GPIB, RS-232
AC Current Accuracy	±0.1%
Frequency Range	0.1Hz to 300kHz
Display	VFD
Type	Digital
Power Supply	100-240V AC, 50/60Hz
Current Range (DC)	100 μA to 3 A
Current Accuracy (DC)	±0.01%
Current Range (AC)	100 μA to 3 A
Current Accuracy (AC)	±0.1%
DC Current Range	100 μA to 3 A
AC Current Range	100 μA to 3 A
