3-12 Keysight B1505A User’s Guide, Edition 12
Accessories
• HCSMU1 and HCSMU2 input connectors
Force BNC connector and Sense triaxial connector. For connecting 16493S
HCSMU cable or 16493S-021 Dual HCSMU combination adapter from the
HCSMU. MCSMU can be used. Then use 16494A triaxial cables and
N1254A-104 adapter.
2. Interlock connector
Interlock connector. For connecting 16493J interlock cable from B1505A.
3. MF CMU Input connectors Hcur, Hpot, Lpot, and Lcur (N1259A-020)
BNC connectors. For connecting N1300A cable from the MFCMU.
4. Module Selector Input (N1259A-300)
• HPSMU3 input connectors
Force and Sense triaxial connectors. For connecting 16493K Kelvin triaxial
cable or 16494A triaxial cable from the HP/MPSMU.
• HVSMU2 input connector
HV(jack) connector. For connecting 16493T HVSMU cable from the
HVSMU or the HVMCU High.
• GNDU2 input connector
GNDU triaxial connector. For connecting 16493L GNDU cable from the
GNDU or the HVMCU Low.
• HCSMU3 input connectors
Force BNC connector and Sense triaxial connector. For connecting 16493S
HCSMU cable or 16493S-021 Dual HCSMU combination adapter from the
HCSMU. Maximum current must be ± 30 A to prevent the module selector
from performance degradation and failure.
NOTE Do not put any conductor on the HCSMU Low Force and Low Sense terminals,
outer conductor of the coaxial connectors. Putting conductor of circuit common,
chassis ground, or any potential on causes the measurement error.
5. Digital I/O connector (N1259A-300)
For connecting 16493G cable from the Digital I/O connector of B1505A or
N1266A expander.
6. LINE input receptacle (N1259A-300)
AC power cable is connected to this receptacle.
