3-54 Keysight B1505A User’s Guide, Edition 12
Accessories
• Prober System Cable (N1254A-524)
This is the cable for extending the N1265A’s Selector Output and Gate terminals
to a prober station. Cable length is 1.8 m. Prober side connector type and the
maximum voltage/current are shown in Table 3-6.
This cable internally connects Selector Output Low Sense and Gate Low.
Table 3-6 Prober Side Connectors and Maximum Voltage/Current of N1254A-524
WARNING For using the prober system cable safely
Never connect the interlock cable to the N1265A.
Never leave and use the N1265A in the condition that the clear plastic plates
are removed from its fixture cover.
Pour utiliser le système de sonde en toute sécurité
Ne jamais connecter le câble de verrouillage au N1265A.
Ne jamais ôter les plaques en plastique transparent du couvercle d'appareil du
N1265A.
CAUTION Do not apply voltage/current over the maximum limit of the cable.
Connector
label
Connector
type
N1265A output terminals
to extend
Maximum
voltage
Maximum
current
High Force Banana(jack) Selector Output High Force
3000 V
39 A dc,
500 A pulse
a
a. Pulse of 1 ms pulse width and 0.4 % duty cycle
Low Force Banana(jack) Selector Output Low Force
200 V
High Sense HV(jack) Selector Output High Sense
3000 V
1 A dc,
20 A pulse
Low Sense BNC(f) Selector Output Low Sense
200 V
Gate Low
Gate BNC(f) Gate High
200 V
