3-68 Keysight B1505A User’s Guide, Edition 12
Accessories
• Power switch
Turns on/off the N1268A.
• High Voltage Enable switch
Enables/disables high voltage output. This red switch lights when the N1268A is
in the high voltage output enable status.
If the Power switch is set to the on position while this switch is in the on
position, the high voltage output is not enabled. Then press this switch to set it to
the off position, and press the switch again to enable the high voltage output.
WARNING The red light indicates that hazardous voltage (maximum ± 10 kVdc) may
appear at the High terminal.
Le témoin rouge indique qu'une tension dangereuse (maximum ± 10 kV CC)
risque d'apparaître au niveau de la borne High.
• Interlock Input and Output
Interlock connector. Input connector is for connecting 16493J interlock cable
from B1505A. And Output connector is for connecting 16493J interlock cable
from test fixture, prober station, and such.
WARNING Potentially hazardous voltage may be present at the High terminal when the
interlock terminals are shorted on test fixture, prober station, and such.
Une tension potentiellement dangereuse peut être présente à la borne High
lorsque les bornes de verrouillage sont court-circuitées sur l'équipement de
test, la station de sonde et autres.
• Digital I/O connector
For connecting 16493G cable from the Digital I/O connector of B1505A,
N1265A test fixture, or N1266A current expander.
• MCSMU/HCSMU V Control Force and Sense
Triaxial connectors. For connecting 16494A triaxial cables from Force and
Sense connectors of the MCSMU. HCSMU is substitutable. Then use 16493S
HCSMU cable, N1254A-103 adapter for Force, and N1254A-517 adapter for
Sense.
• MCSMU I Control Force and Sense
Triaxial connectors. For connecting 16494A triaxial cables from Force and
Sense connectors of the MCSMU. HCSMU is NOT substitutable.
To Next Page
