Keysight B1505A User’s Guide, Edition 12 3-73
Accessories
9. Connect the cable from the temperature controller to the Thermo plate adapter.
10. Set the hood on the test fixture, instead of the fixture cover.
11. Leave the fixture cover open and perform measurement.
WARNING Hazardous voltage, instrument maximum output voltage may appear at the
measurement terminals if the hood or fixture cover is closed.
Une tension dangereuse, une tension de sortie maximale de l'appareil peut
apparaître aux bornes de mesure si le capot ou couvercle de l'équipement est
fermé.
WARNING Make sure that the hood is closed properly before starting measurement. Do
not perform the measurement when a wire is protruding from the hood.
Assurez-vous que le capot est fermé correctement avant de commencer la
mesure. Ne pas effectuer la mesure lorsqu’un câble dépasse du capot de
l'appareil.
N1271A-002 Thermostream Compatible Enclosure for N1265A
(3kV IV)
The N1271A-002 is an enclosure to enable thermal testing (-50 °C to +220 °C) by
creating an interface between the N1265A and an inTEST Thermostream. For the
Thermostream, contact inTEST Corporation.
This option includes the following components:
•Adapter
Adapter for connecting the enclosure to the test fixture. The output terminals
except for BiasTee, K Thermocouple, and UHV are connected to the enclosure.
• Pedestal
This supports the enclosure.
•Enclosure
A heat-resistant enclosure adapted with the interlock. Use this instead of the
fixture cover. The enclosure cover on the top surface is the docking interface
with the Thermostream.
• Test leads and connection kit for thermal test (N1254A-557)
• Six 20 cm small alligator clip - lug cables, six banana plugs, six nuts, and six
spare clips
