3-86 Keysight B1505A User’s Guide, Edition 12
Accessories
For connecting a prober station, use the SHV cable, manipulator, and such.
d. AC/DC Guard output connector
SHV(jack) connector. If the N1273A fixture is used, connect the composite
cable (B1507-61720) from the AC/DC Guard input connector of the
N1273A.
For connecting a prober station, use the SHV cable, manipulator, and such.
e. HVSMU output connector
HV(jack) connector. Connect the 16493T HVSMU cable from the HVSMU
input connector of the used accessory, the N1258A selector or the
N1259A/N1265A fixture. You do not need to switch the connection between
I-V and C-V measurements if you use this connector.
f. Interlock output connector
Interlock connector. If the N1273A fixture is used, connect the composite
cable (B1507-61720) from the Interlock connector of the N1273A.
For connecting a prober station, connect the 16493J interlock cable from the
interlock circuit of the prober station.
g. Frame ground terminal
If the N1273A fixture is used, connect the composite cable (B1507-61720)
from the frame ground terminal of the N1273A.
4. LINE input receptacle and power switch
The AC power cable is connected to this receptacle. The power switch turns
on/off the N1272A.
NOTE To prevent the occurrence of forgetting to turn on the selector, it is recommended to
turn the selector on before turning on the B1505A mainframe.
NOTE The selector may emit a noise sound during operation. However, this is not an
abnormal status.
