Keysight B1505A User’s Guide, Edition 12 3-85
Accessories
BNC connectors. For connecting the N1300A-001 cable (1.5 m) from the
MFCMU.
b. SMU input connectors
Force and Sense triaxial connectors. For connecting the 16494A triaxial
cable from the MPSMU.
c. GNDU input connector
GNDU triaxial connector. For connecting the 16493L GNDU cable from the
GNDU.
For the measurement using the N1258A selector or the N1259A/N1265A
fixture, open this terminal. The GNDU must be connected to the used one.
d. HVSMU input connector
HV(jack) connector. For connecting the 16493T HVSMU cable from the
HVSMU.
e. Interlock input connector
Interlock connector. For connecting the 16493J interlock cable from
B1505A.
For the measurement using the N1259A/N1265A fixture, open this terminal.
The B1505A Interlock must be connected to the used one.
3. Output
a. Collector/Drain output connector
SHV(jack) connector. If the N1273A fixture is used, connect the composite
cable (B1507-61720) from the Collector/Drain input connector of the
N1273A.
For connecting a prober station, use the SHV cable, manipulator, and such.
b. Base/Gate output connector
SHV(jack) connector. If the N1273A fixture is used, connect the composite
cable (B1507-61720) from the Base/Gate input connector of the N1273A.
For connecting a prober station, use the SHV cable, manipulator, and such.
c. Emitter/Source output connector
SHV(jack) connector. If the N1273A fixture is used, connect the composite
cable (B1507-61720) from the Emitter/Source input connector of the
N1273A.
