3-88 Keysight B1505A User’s Guide, Edition 12
Accessories
1. Hazardous voltage status indicator
This red LED lights when a source channel applies dangerous voltage. This
indicator is connected to the B1505A via the Interlock connector and works with
the High Voltage indicator on the B1505A’s front panel.
Warning labels written in French, German, and Japanese are furnished. Attach
the label to the front panel of the fixture if you need.
WARNING The red light indicates that hazardous voltage (maximum ± 3000 Vdc) may
appear at measurement terminals. Check this indicator before accessing.
Le témoin rouge indique qu'une tension dangereuse (maximum ± 3000 V CC)
risque d'apparaître au niveau des bornes de mesure. Vérifiez cet indicateur
avant d’accéder.
2. Terminal for connecting wrist strap
3. Fixture cover
The fixture cover should be closed to avoid electrical shock by touching the
measurement terminals and to prevent a device under test from external noise.
When the fixture cover is open, maximum SMU output is limited to ± 42 V.
WARNING Hazardous voltage, instrument maximum output voltage may appear at the
measurement terminals if the fixture cover is closed.
Une tension dangereuse, une tension de sortie maximale de l'appareil peut
apparaître aux bornes de mesure si le couvercle de l'équipement est fermé.
WARNING Make sure that the cover is closed properly before starting measurement. Do
not perform the measurement when a wire is protruding from the fixture cover.
Assurez-vous que le couvercle est fermé correctement avant de commencer la
mesure. Ne pas effectuer la mesure lorsqu’un câble dépasse du couvercle de
l'appareil.
