3-100 Keysight B1505A User’s Guide, Edition 12
Accessories
b. High Force and Sense input connectors
HV(jack) connectors. For connecting a HV coaxial cable (N1274-61721)
from the High Force connector of the N1258A, and HV triaxial cable
(N1274-61720) from the High Sense connector of the N1258A. Both cables
are supplied with the N1274A.
c. Relay Control Input connector
D-sub 15 pin connector. For connecting the D-sub 15 pin cable
(N1274-61722) from the External Relay Control Output connector of the
N1258A. The D-sub 15 pin cable (N1274-61722) is supplied with the
N1274A.
2. Output
a. High Force output connector
Banana(jack) connector. This must be extended to the Collector/Drain
terminal of a DUT. For making the connection, use a cable with
banana(plug) connector, manipulators, and such.
b. Low Force output connector
Banana(jack) connector. This must be extended to the Emitter/Source
terminal of a DUT. For making the connection, use a cable with
banana(plug) connector, manipulators, and such.
c. High Sense output connector
HV(jack) connector. This must be extended to the Collector/Drain terminal
of a DUT. For making the connection, use a cable with HV(plug) connector,
manipulators, and such.
d. Low Sense output connector
BNC connector. This must be extended to the Emitter/Source terminal of a
DUT. For making the connection, use a cable with BNC(m) connector,
manipulators, and such.
e. Gate output connector
BNC connector. This must be extended to the Base/Gate terminal of a DUT.
For making the connection, use a cable with BNC(m) connector,
manipulators, and such.
This is connected to the High force/sense terminals of MCSMU/HCSMU
connected for driving the DUT.
