Keysight B1505A User’s Guide, Edition 12 2-21
Introduction
Accessories and Options
N1254A N1254A-507 HV(plug)-HV(plug) coaxial cable, 1.5 m, 1 ea.
N1254A-508 Connection wire, banana-to-banana, red 1 ea.
N1254A-509 Connection wire, banana-to-banana, black 1 ea
N1254A-510 Dolphin clip adapter, black 1 ea. and red 1ea.
N1254A-511 Cable lug adapter, black 1 ea. and red 1ea.
N1254A-512 SHV(plug)-SHV(plug) cable, 1 ea.
N1254A-513 SHV(jack)-banana adapter, 1 ea.
N1254A-514 BNC(m)-BNC(m) adapter, 1 ea.
N1254A-515 BNC(f)-BNC(m)-BNC(f) adapter, 1 ea.
N1254A-516 BNC(f)-BNC(f)-BNC(f) adapter, 1 ea.
N1254A-517 Triax(f)-Triax(m) adapter, shield separated, 1 ea.
N1254A-518 SHV(plug)-SHV(plug) coaxial cable, 1.5 m, 1 ea.
N1254A-520 UHV(plug) to no connector cable, 1 m, 1 ea. and SHV(plug) to no
connector cable, 1 m, 1 ea.
N1254A-521 UHV(jack)-UHV(jack) adapter, 1 ea. and SHV(jack)-SHV(jack) adapter, 1
ea.
N1254A-522 Connection wire, banana-to-banana, maximum 1500 A, 2 ea.
N1254A-523 Banana to no connector wire, maximum 1500 A, 1 m, 2 ea.
N1254A-524 500 A Ultra High Current Prober System Cable, 1.8 m, 1 ea.
N1254A-525 SHV Cable Assy 1.5m - SHV Plug To Open-end, 1 ea.
N1254A-526 Ultra High Current Cable, 2m, No Connectors At Either End, 1 ea.
N1254A-527 PTFE Standoff, Jack, 4 ea.
N1254A-528 PTFE Standoff With Banana Plug, 4 ea.
N1254A-554 Thermocouple, Type K, 75 cm, 2 ea.
N1254A-556 Test Leads and Connection Kit for Capacitance Test,
four 20 cm alligator clip - lug cables, four banana plugs, four nuts, and four
spare clips
Model
Number
Option Item Description
To Next Page
