2-22 Keysight B1505A User’s Guide, Edition 12
Introduction
Accessories and Options
N1254A N1254A-557 Test Leads And Connection Kit For Thermal Test with N1271A,
• six 20 cm small alligator clip - lug cables, six banana plugs, six nuts,
and six spare clips
• two 20 cm large alligator clip - lug cables, two banana plugs, and two
nuts
• four 30 cm small alligator clip - lug cables, four banana plugs, four
nuts, and four spare clips
• two 30 cm large alligator clip - lug cables, two banana plugs, and two
nuts
N1254A-558 SHV cable, 3 m, 1 ea.
N1258A Module Selector
N1259A Test Fixture
N1259A-001 Test fixture, built-in HPSMU protection adapter, built-in GNDU protection
adapter, four black connection wire, and six red connection wire, and
N1259A-010, 1 ea.
N1259A-010 Kelvin socket module for inline package device
N1259A-011 Universal socket module for power device
N1259A-012 Blank PTFE board
N1259A-013 Curve tracer test adapter socket module
N1259A-014 Gate charge socket module
N1259A-020 Built-in high voltage bias-tee (furnished with two SHV-SHV cables and
two SHV-banana adapters)
N1259A-021 1 M resistor box
N1259A-022 100 k resistor box
N1259A N1259A-030 1 k resistor box
N1259A-035 Universal resistor box
N1259A-300 Built-in module selector
N1260A High voltage bias-tee
Model
Number
Option Item Description
