Keysight B1505A User’s Guide, Edition 12 2-23
Introduction
Accessories and Options
N1261A Protection Adapter
N1261A-001 HPSMU protection adapter, Triax(f)
N1261A-002 GNDU protection adapter, BNC(f)
N1261A-003 HPSMU protection adapter, HV(jack)
N1261A-004 GNDU protection adapter, SHV(jack)
N1262A High voltage resistor box
N1262A-001 1 M resistor box, SHV(jack)
N1262A-002 100 k resistor box, SHV(jack)
N1262A-010 1 k resistor box, Triax(f)
N1262A-011 1 k resistor box, SHV(jack)
N1262A-020 Universal resistor box, Triax(f)
N1262A-021 Universal resistor box, SHV(jack)
N1262A-023 Universal resistor box, UHV(jack), with UHV(plug)-UHV(plug) cable, 1.5
m
N1262A-036 50 termination adapter
N1265A Ultra High Current Expander/Fixture
N1265A-001 Test fixture, built-in 500 A ultra high current expander, built-in module
selector, four black connection wire, and four red connection wire,
N1265A-002, 1 ea. and N1265A-010, 1 ea.
N1265A-002 Blank silicon plate
N1265A-010 Kelvin socket module for inline package device, maximum 500 A
(furnished with two high current connection wire (18 cm), two sense
connection wire (18 cm), and two gate connection wire (25 cm))
N1265A-011 Universal socket module for power device, maximum 1500 A
N1265A-013 Curve tracer test adapter socket module
N1265A-014 Gate charge socket module
N1265A-015 Built-in 1500 A ultra high current expander (replaced with built-in 500 A
ultra high current expander)
N1265A-035 Universal resistor box
N1265A-040 Protection adapter for Gate/SMU
Model
Number
Option Item Description
