[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:FTIMe <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:FTIMe? [MIN|MAX,] <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:FTIMe <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:FTIMe? [MIN|MAX,] <step#>, (@<chanlist>)
Specifies the fall time of the trapezoid in seconds for Arb sequence steps.
Parameter Typical Return
0 – 262.144 | MIN | MAX, *RST 1 <fall time>
Step 0 - 99, *RST 0 (none)
Programs a fall time for thecurrent trapezoid: ARB:CURR:TRAP:FTIM 10,(@1)
Programs a fall time for thevoltagetrapezoid: ARB:VOLT:TRAP:FTIM 10,(@1)
Programs a fall time for step 0:ARB:SEQ:STEP:CURR:TRAP:FTIM 10, 0,(@1)
[SOURce:]ARB:CURRent:TRAPezoid:RTIMe <value>, (@<chanlist>)
[SOURce:]ARB:CURRent:TRAPezoid:RTIMe? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:TRAPezoid:RTIMe<value>, (@<chanlist>)
[SOURce:]ARB:VOLTage:TRAPezoid:RTIMe? [MIN|MAX,] (@<chanlist>)
Specifies the rise time of the trapezoid in seconds. Referenced to t1 in the Trapezoid diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:RTIMe <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:RTIMe? [MIN|MAX,] <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:RTIMe <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:RTIMe? [MIN|MAX,] <step#>, (@<chanlist>)
Specifies the rise time of the trapezoid in seconds for Arb sequence steps.
Parameter Typical Return
0 – 262.144 | MIN | MAX, *RST 1 <risetime>
Step 0 - 99, *RST 0 (none)
Programs a rise timefor thecurrent trapezoid: ARB:CURR:TRAP:RTIM 10,(@1)
Programs a rise timefor thevoltagetrapezoid: ARB:VOLT:TRAP:RTIM 10,(@1)
Programs a rise timefor step 0:ARB:SEQ:STEP:CURR:TRAP:RTIM 10, 0,(@1)
[SOURce:]ARB:CURRent:TRAPezoid:STARt[:LEVel] <value>, (@<chanlist>)
[SOURce:]ARB:CURRent:TRAPezoid:STARt[:LEVel]? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:TRAPezoid:STARt[:LEVel] <value>, (@<chanlist>)
[SOURce:]ARB:VOLTage:TRAPezoid:STARt[:LEVel]? [MIN|MAX,] (@<chanlist>)
Specifies the initial and final current or voltage level of the trapezoid. Referenced to I0 and V0 in the
Trapezoid diagrams.
7 SCPI Programming Reference
256 Keysight N6705C Operating and Service Guide
