OUTPut:PROTection:WDOG:DELay <value>
OUTPut:PROTection:WDOG:DELay? [MIN|MAX,]
Sets the watchdog delay time. When the watchdog timer is enabled, the output is disabled if there is
no SCPI I/O activity on any remote interface (USB, LAN, GPIB) within the delay time. The watchdog
timer function is NOT reset by activity on the front panel - the output will still shut down after the time
period has elapsed. Programmed values can range from 1 to 3600 seconds in 1 second increments.
Parameter Typical Return
0 - 3600|MIN|MAX, *RST 60 <delay value>
Sets a watchdog delay of 600 seconds: OUTP:PROT:WDOG:DEL 600
OUTPut:RELay:POLarity NORMal|REVerse, (@<chanlist>)
OUTPut:RELay:POLarity? (@<chanlist>)
Sets the polarity of the output relays on power modules with polarity reversal relays installed (Option
760). Polarity reversal affects both the output and the sense terminals.
Normal causes the output polarity to be the same as the output connector labeling.
Reverse causes the output polarity to be the reverse of the output connector labeling. This briefly
turns the output off while the output and sense terminal polarities are switched.
When installed on models N6742B and N6773A, Option 760 (Polarity Reversal) will limit
the output current of these models to a maximum of 10 A.
Option 760 is not available on models N6741B, N6751A, N6752A, N676xA, or N678xA
SMU.
Parameter Typical Return
NORMal|REVerse, *RST NORMal NORM or REV
Sets the outputpolarity to Reverse: OUTP:REL:POL REV (@1)
Keysight N6705C Operating and Service Guide 313
7 SCPI Programming Reference
