Parameter Typical Return
0|OFF|1|ON, *RST OFF 0or1
Enable current measurement autoranging: SENS:CURR:RANG:AUTO ON, (@1)
l Autoranging does not include the 10 μA range, which must be selected individually.
SENSe:DLOG:CURRent[:DC]:RANGe[:UPPer] <value>, (@<chanlist>)
SENSe:DLOG:CURRent[:DC]:RANGe[:UPPer]? [MIN|MAX,] (@<chanlist>)
SENSe:DLOG:VOLTage[:DC]:RANGe[:UPPer] <value>, (@<chanlist>)
SENSe:DLOG:VOLTage[:DC]:RANGe[:UPPer]? [MIN|MAX,] (@<chanlist>)
Selects the internal datalog current or voltage measurement range. The value that you enter must be
the highest value that you expect to measure. Units are in amperes or volts. The instrument selects
the range with the best resolution for the value entered.
Parameter Typical Return
0 to maximum|MIN|MAX, *RST MAX <maximum value of range>
Selects the 1 A range: SENS:DLOG:CURR:RANG 1, (@1)
Selects the 2 V range: SENS:DLOG:VOLT:RANG 2, (@1)
l When queried, the returned value is the maximum current or voltage that can be measured on the
range that is presently set.
SENSe:DLOG:CURRent[:DC]:RANGe:AUTO 0|OFF|1|ON, (@<chanlist>)
SENSe:DLOG:CURRent[:DC]:RANGe:AUTO? (@<chanlist>)
SENSe:DLOG:VOLTage[:DC]:RANGe:AUTO 0|OFF|1|ON , (@<chanlist>)
SENSe:DLOG:VOLTage[:DC]:RANGe:AUTO? (@<chanlist>)
Enables or disables seamless datalog measurement autoranging.
Parameter Typical Return
0|OFF|1|ON, *RST OFF 0or1
Enable seamless internal datalog measurement autoranging:
SENS:DLOG:CURR:RANG:AUTO ON, (@1)
SENS:DLOG:VOLT:RANG:AUTO ON, (@1)
l Autoranging does not include the 10 μA range, which must be selected individually.
SENSe:DLOG:FUNCtion:CURRent 0|OFF|1|ON, (@<chanlist>)
SENSe:DLOG:FUNCtion:CURRent? (@<chanlist>)
SENSe:DLOG:FUNCtion:VOLTage 0|OFF|1|ON, (@<chanlist>)
SENSe:DLOG:FUNCtion:VOLTage? (@<chanlist>)
Enables or disables the internal datalog current or voltage measurement function.
