Data Log and Digitize Mode Default Settings
On entering data log or digitize mode, the DMM configures these settings:
l Trigger count set to 1 (trigger count is normally infinite when in Local and is not settable from the
front panel).
l Secondary measurements are turned off.
l Math smoothing is turned off.
l Statistics are cleared.
l Histogram is cleared.
l Trend chart is changed from the continuous, bucketized mode, to simple data graph.
Additional Data Log Default Settings
On entering data log mode, the DMM configures these settings:
l Trigger source is set to auto.
l Trigger delay is set to auto.
l Pretrigger count is set to zero.
l Samples per trigger is set according to the data log duration (time or samples).
l Sample timer is put in timer (not immediate) mode and sample time is set according to the data log
sample interval.
Features and Functions
48
Keysight Truevolt Series Operating and Service Guide
