AC Voltage Gain and Flatness Calibration
This calibration procedure applies to all models (34460A/61A/65A/70A).
Review Test Considerations and Flatness Calibration Considerations before performing any calibration.
Configuration: AC Voltage
All AC calibration procedures use the 3 Hz bandwidth measurement filter.
1.
Configure each function and range in the order shown in the table below.
2.
Apply the input signal shown in the Input column.
3.
Enter the actual applied input voltage amplitude (see Entering Calibration Values). A Calibration Step
Succeeded message indicates success; if the display shows Calibration Step Failed, check the input
value, range, function, and entered calibration value and repeat the calibration step.
4.
Repeat steps 1 through 3 for each flatness calibration point shown in the table.
5.
Store the new calibration constants (see Storing the Calibration Constants).
Each voltage and frequency takes approximately 2.5 seconds to complete.
Input Instrument
Vrms Frequency Range
100 mV
5 kHz, 10 kHz, 20 kHz, 35 kHz, 50 kHz, 75 kHz, 100 kHz,
200 kHz, 300 kHz, 390 kHz, 400 kHz, 220 Hz, 1000 Hz
100 mV
1 v
5 kHz, 10 kHz, 20 kHz, 35 kHz, 50 kHz, 75 kHz, 100 kHz,
200 kHz, 300 kHz, 390 kHz, 400 kHz, 220 Hz, 1000 Hz
1 V
10 V
5 kHz, 10 kHz, 20 kHz, 35 kHz, 50 kHz, 75 kHz, 100 kHz,
200 kHz, 300 kHz, 390 kHz, 400 kHz, 220 Hz, 1000 Hz
10 V
50 V
5 kHz, 10 kHz, 20 kHz, 35 kHz, 50 kHz, 75 kHz, 100 kHz,
200 kHz, 300 kHz, 390 kHz, 400 kHz, 220 Hz, 1000 Hz
100 V
500 V 1000 Hz 750 V
Next Procedure
Calibration Adjustment Procedures
544
Keysight Truevolt Series Operating and Service Guide
