Page #514 background imageLoading...
Page #514 background image
Frequency Accuracy Verification
Configuration: Frequency (CONFigure:FREQuency DEF, MIN)
1.
Make sure you have read Test Considerations.
2.
Select the Frequency function, default range, 3 Hz filter, and 1 second aperture.
3.
Connect the Keysight 33500B Series Function/Arbitrary Waveform Generator to the input terminals.
For the 34461A/65A/70A, use the front panel input terminals and select the front input terminals with
the Front/Rear switch.
4.
Select each range in the order shown below. Provide the indicated input voltage and frequency. Com-
pare measurement results to the test limits shown below. (Be certain to allow for appropriate source
settling.)
Values for 34460A DMM
Input Error from Nominal
Vrms Frequency Range
Quick
Check
24 hours 90 days 1 year 2 years
0.1 Vrms 10 Hz 1 Vrms ± 3 mHz ± 3.5 mHz
0.01 Vrms 300 kHz 0.1 Vrms Q ± 60 Hz ± 240 Hz ± 360 Hz ± 510 Hz
Values for 34461A DMM
Input Error from Nominal
Vrms Frequency Range
Quick
Check
24 hours 90 days 1 year 2 years
0.1 Vrms 10 Hz 1 Vrms ± 3 mHz ± 3.5 mHz
0.01 Vrms 300 kHz 0.1 Vrms Q ± 60 Hz ± 180 Hz ± 300 Hz ± 450 Hz
Values for 34465A and 34470A DMMs
Input Error from Nominal
Vrms Frequency Range
Quick
Check
24 hours 90 days 1 year 2 years
0.1 Vrms 10 Hz 1 Vrms ± 3 mHz
0.01 Vrms 300 kHz 0.1 Vrms Q ± 60 Hz ± 150 Hz ± 210 Hz ± 270 Hz
Q: Quick performance verification test point.
Keysight Truevolt Series Operating and Service Guide
515
