Panel Memory
You can save up to three sets of test conditions (the test conditions currently being used) to internal
memory.
On the TOS5302, you can save two sets of test conditions with each set containing a combination of
an ACW test and an IR test (for auto tests).
Test conditions that can be saved
■ Test condition settings
Setting TOS5300 TOS5301 TOS5302
Test mode ACW ACW, DCW ACW, IR
ACW→IR, IR→ACW
ACW Test voltage Yes Yes Yes
Limit voltage Yes Yes Yes
Output frequency Yes Yes Yes
Upper limit Yes Yes Yes
Lower limit Yes Yes Yes
Test time Yes Yes Yes
Voltage rise time Yes Yes Yes
Voltage fall time Yes Yes Yes
Start voltage Yes Yes Yes
DCW Test voltage No Yes No
Limit voltage No Yes No
Upper limit No Yes No
Lower limit No Yes No
Test time No Yes No
Voltage rise time No Yes No
Start voltage No Yes No
Judgment wait time No Yes No
IR Test voltage No No Yes
Limit voltage No No No
Upper limit No No Yes
Lower limit No No Yes
Test time No No Yes
Judgment wait time No No Yes
Current detection
response speed
No No Yes
ACW DCW IR
Test voltage 0.00 kV to 5.50 kV 0.00 kV to 6.20 kV 25 V / 50 V / 100 V / 125 V /
250 V / 500 V /1000 V
Limit voltage 0.00 kV to 5.50 kV 0.00 kV to 6.20 kV —
Output frequency 50 Hz / 60 Hz — —
Upper limit 0.01 mA to 110 mA 0.01 mA to 11 mA OFF / 30kΩ to 5.00 GΩ
Lower limit OFF / 0.01 mA to 110 mA OFF / 0.01 mA to 11 mA OFF / 30kΩ to 5.00 GΩ
Test time OFF /0.1 s to 999 s OFF /0.1 s to 999 s OFF /0.1 s to 999 s
Voltage rise time 0.1 s to 10.0 s 0.1 s to 10.0 s —
Voltage fall time OFF / 0.1 s — —
Start voltage OFF / 50 % OFF / 50 % —
Judgment wait time — 0.1 s to 10.0 s 0.1 s to 10.0 s
Current detection
response speed
——
Fast / Mid / Slow
