90 TOS5300
Configuration Settings
Status Signal Output settings
You can set the following settings on the Status Signal Output screen.
1
2
3
H.V ON OFF
Test OFF
Pass ON
Upper Fail OFF
Lower Fail ON
Ready ON
Protection ON
Power ON OFF
2.Status Signal Output
----
Down
Up
Menu
1
2
3
4
5
6
7
8
Item Description Panel operation
1H.V ON
Sets whether the 24 VDC output is generated while there is a residual voltage
and during tests.
MEMORY 2 and MEMORY 3 keys
ON
Turns the 24 VDC output on while there is a residual voltage and
during tests.
Rotary knob
OFF
Turns the 24 VDC output off while there is a residual voltage and
during tests.
2Test
Sets whether the 24 VDC output is generated while tests are being performed
with the test voltage at the specified voltage value.
1
MEMORY 2 and MEMORY 3 keys
ON Turns the 24 VDC output on during testing.
Rotary knob
OFF Turns the 24 VDC output off during testing.
3 Pass Sets whether the 24 VDC output is generated after a PASS judgment has
occurred.
MEMORY 2 and MEMORY 3 keys
ON Turns the 24 VDC output on after a PASS judgment has occurred.
Rotary knob
OFF Turns the 24 VDC output off after a PASS judgment has occurred.
4 Upper Fail
Sets whether the 24 VDC output is generated after an upper limit FAIL judgment
has occurred.
MEMORY 2 and MEMORY 3 keys
ON
Turns the 24 VDC output on after an upper limit FAIL judgment has
occurred.
Rotary knob
OFF
Turns the 24 VDC output off after an upper limit FAIL judgment has
occurred.
5Lower Fail
Sets whether the 24 VDC output is generated after a lower limit FAIL judgment
has occurred.
MEMORY 2 and MEMORY 3 keys
ON
Turns the 24 VDC output on after a lower limit FAIL judgment has
occurred.
Rotary knob
OFF
Turns the 24 VDC output off after a lower limit FAIL judgment has
occurred.
6 Ready Sets whether the 24 VDC output is generated while the READY LED is lit. MEMORY 2 and MEMORY 3 keys
ON Turns the 24 VDC output on while the READY LED is lit.
Rotary knob
OFF Turns the 24 VDC output off while the READY LED is lit.
7Protection
Sets whether the 24 VDC output is generated while the TOS5300 Series is in the
protection state.
MEMORY 2 and MEMORY 3 keys
ON
Turns the 24 VDC output on when the TOS5300 Series enters the
protection state.
Rotary knob
OFF
Turns the 24 VDC output off when the TOS5300 Series enters the
protection state.
8 Power ON Sets whether the 24 VDC output is generated while the POWER switch is on. MEMORY 2 and MEMORY 3 keys
ON Turns the 24 VDC output on when the POWER switch is turned on.
Rotary knob
OFF Turns the 24 VDC output off when the POWER switch is turned on.
1 The 24 VDC output is not generated during voltage rise time (Rise Time) and voltage fall time (Fall Time).
