52 TOS5300
Setting Other Test Conditions
Voltage rise time
Separate from the test time, you can set the time that the TOS5300 Series takes to raise the voltage
to the test voltage during AC and DC withstanding voltage tests.
Voltage fall time
Separate from the test time, you can set the time that the TOS5300 Series takes to lower the voltage
after an AC withstanding voltage test ends. This setting is only used when a PASS judgment occurs.
Frequency
You can set the frequency of the test voltage of AC withstanding voltage tests.
Current detection response speed
You can select the current detection response speed when a value less than or equal to the lower
limit is measured during insulation resistance (IR) tests. You can select from Fast, Mid, and Slow.
Time 0.1 s to 10.0 s
0.1 s The output voltage falls over approximately 0.1 seconds after a test
ends with a PASS judgment.
OFF The output voltage falls immediately after a test ends with a PASS
judgment.
50 Hz The test voltage frequency is set to 50 Hz.
60 Hz The test voltage frequency is set to 60 Hz.
5302
Fast Use this setting when the test time is short or when you want to reduce takt time.
This setting makes the TOS5300 Series more susceptible to external noise.
Set the test time (Test Time) to 0.1 seconds or more.
Mid Use this setting for normal tests.
Set the test time (Test Time) to 0.3 seconds or more.
Slow Use this setting when the Fast or Mid setting, which makes the TOS5300 Series
susceptible to external noise, produces highly inconsistent measured values.
Set the test time (Test Time) to 0.5 seconds or more.
