TOS5300 83
Specifications
8
Specifications
General
TOS5300 TOS5301 TOS5302
SIGNAL I/O (continued)
18 L-FAIL
O
On continuously when LOWER FAIL results from judgment because a value less than or
equal to the lower limit is detected.
19 READY O On when the TOS5300 Series is waiting (when it is in the READY state).
20 PROTECTION O On when protective features have activated (the TOS5300 Series is in the Protection state).
21 START I Start signal input terminal.
22 STOP I Stop signal input terminal.
23 ENABLE I Start signal enable signal input terminal.
24 +24V — +24 V internal power supply output terminal; maximum output current 100 mA.
25 COM — Circuit common terminal.
STATUS SIGNAL OUTPUT Output terminal for a warning light.
+ Terminal A +24 V signal is generated from this terminal when output has been turned on.
COM +24 V circuit common terminal
1 The input signals are all low-active control. The input terminal is pulled up to +15 V by a resistor. Leaving the input terminal open is
equivalent to applying a high level signal.
TO5S300 TOS5301 TOS5302
Display VFD: 256 × 64 dots + 4 status indicators
Backup battery life 3 years (at 25 °C or 77 °F)
Environment Installation location Indoors, at a height of up to 2000 m
Spec guaranteed
range
Tempe rature 5 °C to 35 °C (41 °F to 95 °F)
Humidity 20 %rh to 80 %rh (no condensation)
Operating range Temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity 20 %rh to 80 %rh (no condensation)
Storage range Temperature -20 °C to 70 °C (-4 °F to 158 °F)
Humidity 90 %rh or less (no condensation)
Power supply Nominal voltage range (allowable voltage
range)
100 VAC to 240 VAC (90 VAC to 250 VAC)
Power
consumption
When no load is
connected (READY)
100 VA or less
When rated load is
connected
800 VA max.
Allowable frequency range 47 Hz to 63 Hz
Insulation resistance (between AC LINE and the chassis) 30 MΩ or more (500 VDC)
Withstanding voltage (between AC LINE and the chassis) 1400 VAC, 2 seconds (Routine test) / 1500 VAC, 1 minutes (Type test)
Earth continuity 25 AAC, 0.1 Ω or less
Electromagnetic compatibility (EMC)
1
Complies with the requirements of the following directive and standard.
EMC Directive 2004/108/EC
EN 61326-1 (Class A
2
)
EN 55011 (Class A
2
, Group 1
3
)
EN 61000-3-2
EN 61000-3-3
Applicable under the following conditions
The maximum length of all cabling and wiring connected to the
TOS5300 Series must be less than 2.5 m.
The shielded cable is being used when using the SIGNAL I/O.
The high-voltage test lead TL31-TOS is being used.
Electrical discharges are not occurring outside the DUT.
Safety
1
Complies with the requirements of the following directive and standard.
Low Voltage Directive 2006/95/EC
EN 61010-1 (Class I
4
, Pollution degree 2)
