TOS5300 47
5
Withstanding Voltage and Insulation Resistance Tests
Setting Withstanding Voltage Test Conditions
Press FUNCTION to display the AC or DC withstanding voltage test setup screen.
p.35
For details on how to select settings and enter values, see ”Panel Operation Basics.”
p.26
For details on how to connect the TOS5300 Series to the DUT, see ”Connecting to the Device under
Test (DUT ).”
p.46 , p.51
For details on the LOWER and UPPER settings, see ”About Judgment.” For details on other test
conditions, see ” Setting Other Test Conditions.”
AC withstanding voltage test (ACW) settings
ACW
FUNCTION
ACW / DCW
ACW / IR / AUTO
5300
5301
5302
See
TIMER UPPER
LOWER
10.0
mA
0.01
mA
1.50
kV
60
.
0
s
ACW
0
5.5kV
Limit Voltage 2.00kV
SET UPR/LWR TEST MORE
LIMIT ON/OFF ON/OFF KEY LOCK
LOCAL
SHIFT
Item Description Panel operation
Voltage Sets the test voltage. You cannot specify a voltage that is greater than or equal to the limit voltage. SET key
0.00 kV to 5.50 kV Setting Rotary knob
Limit Voltage Sets the limit voltage. This prevents an unnecessarily high voltage from being applied to the DUT
because of incorrect operations of the TOS5300 Series.
LIMIT (SHIFT+SET) key
0.00 kV to 5.50 kV Setting Rotary knob
Sets the upper limit that is used in judgments. If a current that is greater than or equal to the upper
limit is measured, a U-FAIL judgment occurs.
UPR/ LWR key
0.01 mA to 110 mA Setting Rotary knob
Sets the lower limit that is used in judgments. While LOWER is on, if a current that is less than or
equal to the lower limit is measured, an L-FAIL judgment occurs.
UPR/ LWR key
0.01 mA to 110 mA Setting Rotary knob
OFF The lower limit is not used in judgments.
ON/ OFF (SHIFT+UPR/
LWR) key
Sets the test time. The test time begins when the voltage rise time elapses. The test time begins
when the voltage rise time elapses.
TEST key
0.1 s to 999 s When the specified time elapses, the test ends. Rotary knob
OFF
The set test time is ignored. A PASS judgment is not performed.
Press STOP to stop testing.
ON/ OFF
(SHIFT+TEST) key
Start Voltage Sets the start voltage to 50 % of the test voltage. MORE key
50 % The start voltage is set to 50 % of the test voltage.
Rotary knob
OFF The start voltage is not set.
Rise Time Sets the voltage rise time. MORE key
0.1 s to 10.0 s Setting Rotary knob
