TOS5300 81
Specifications
8
Specifications
Other features
TOS5300 TOS5301 TOS5302
Double action feature (Double Action) Tests can only be started by pressing and releasing STOP and then pressing START within 0.5
seconds of releasing the STOP switch.
Length of time to maintain a PASS
judgment result (Pass Hold)
You can set the length of time to maintain a PASS judgment: 50 ms, 100 ms, 200 ms, 1 s, 2 s,
5 s, or HOLD.
Momentary feature (Momentary) Tests are only executed while the START switch is held down.
Fail mode feature (Fail Mode) This feature enables you to prevent remotely transmitted stop signals from clearing FAIL
judgments and PROTECTION modes.
Timer feature (TIMER) This feature finishes tests when the specified time elapses.
Output voltage monitor feature
(Volt Error)
If output voltage exceeds “setting + 350 V” or is lower than “setting - 350 V,” the TOS5300
Series switches to PROTECTION mode, output is turned off, and testing finishes.
Memory Up to three sets of test conditions can be saved to memory.
Key lock Locks panel key operations (settings and changes).
Protective features Under any of the following conditions, the TOS5300 Series switches to the PROTECTION
state, immediately turns output off, and stops testing. A message is displayed on the screen.
Interlock Protection An interlock signal has been detected.
Power Supply Protection An error was detected in the power supply.
Volt Error Protection While monitoring the output voltage, a voltage outside of the rated limits was detected.
AC or DC withstanding voltage tests: ±350 V
Insulation resistance test: ±(10 % of set + 10 V)
Over Load Protection During a withstanding voltage test, a value that is greater than or equal to the output limit
power was specified.
AC withstanding voltage test: 550 VA. DC withstanding voltage test: 55 VA.
Over Heat Protection The internal temperature of the TOS5300 Series became too high.
Over Rating Protection During a withstanding voltage test, the output current was generated for a length of time
that exceeds the regulated time.
Calibration Protection The specified calibration period has elapsed.
Remote Protection A connection to or disconnection from the front-panel REMOTE connector was detected.
SIGNAL I/O Protection The rear-panel SIGNAL I/O connector’s ENABLE signal has changed.
USB Protection The USB connector has been disconnected while the TOS5300 Series was being controlled
through the USB interface.
System clock Set in the following format: year/month/day hour/minutes/seconds.
Calibration date Set when the TOS5300 Series is calibrated.
Calibration period setting Sets the period before the next calibration is necessary.
Notification of when the calibration
period elapses
Sets the operation that is performed when the specified calibration period elapses.
When the TOS5300 Series turns on, it can display a notification or switch to the protection
mode and disable testing.
