TOS5300 57
Setting Other Test Features
5
Withstanding Voltage and Insulation Resistance Tests
Momentary feature
This feature enables you to perform tests only while you are pressing START. This ensures safe
testing because it means that your hand must be fixed to the panel or to an optional START switch.
Using this feature with the optional RC02-TOS (two-hand-type remote control box p.16 )
provides an even higher level of safety.
While this feature is on, testing stops as soon as you release START. The stop operation is the same
as if you had pressed STOP.
Fail mode feature
This feature enables you to prevent remotely transmitted stop signals from clearing FAIL judgments
and protection modes.
If you are using the optional high voltage test probe (model HP01A-TOS/HP02A-TOS p.17 ),
turn fail mode on. When a test ends with a FAIL judgment, the FAIL judgment is not cleared even if
you let go of the probe. To clear the FAIL judgment, press STOP on the front panel.
Buzzer volume
You can set the volume level of the buzzer that is sounded when PASS and FAIL judgments occur.
When a PASS judgment occurs, the buzzer sounds for approximately 50 ms, regardless of the value
of the Pass Hold setting. When a FAIL judgment occurs, the buzzer sounds until you press STOP.
ON The momentary feature is turned on.
OFF The momentary feature is turned off.
See
ON The fail mode feature is turned on.
OFF The fail mode feature is turned off.
PASS judgment setting range 0 to 10
FAIL judgment setting range 0 to 10
