Kikusui TOS5301 - A List of Default Settings; Initializing the TOS5300 Series

86 TOS5300
A
List of Default Settings
Initializing the TOS5300 Series
While holding down SHIFT, turn the POWER
switch on. “Initializing” will be displayed in the
lower right of the firmware version display
screen, and the TOS5300 Series will be
initialized.
When you initialize the TOS5300 Series, all
settings (such as test conditions) and saved
data are reset to the default values shown below.
Default values
Initializing...
TOS5302 WITHSTANDING VOLTAGE /
INSULATION RESISTANCE TESTER
Version 1.00
KIKUSUI ELECTRONICS CORP.
Item Setting after initialization
Withstanding voltage
test conditions (ACW)
Measurement method RMS
Test voltage 0 V
Test voltage’s limit voltage 5.50 kV
Upper limit 0.02 mA
Lower limit 0.01 mA
Lower limit on and off OFF
Test time 0.1 s
Test timer on and off ON
Start voltage on and off OFF
Voltage rise time 0.1 s
Voltage fall time OFF
Test voltage frequency 50 Hz
Withstanding voltage
test conditions (DCW)
Test voltage 0 V
Test voltage’s limit voltage 6.2 kV
Upper limit 0.02 mA
Lower limit 0.01 mA
Lower limit on and off OFF
Test time 0.1 s
Test timer on and off ON
Start voltage on and off OFF
Voltage rise time 0.1 s
Judgment wait time 0.1 s
Insulation resistance
test conditions (IR)
Test voltage 25 V
Test voltage’s limit voltage 1000 V
Upper limit 100 MΩ
Upper limit on and off OFF
Current detection response speed Mid
Lower limit 1.00 MΩ
