Kikusui TOS5301 - Rear Panel

12 TOS5300
Rear Panel
No. Name Function
1
SIGNAL I/O connector External control signal connector. p.64
2
Air outlet Vent for cooling the TOS5300 Series. —
3
STATUS OUT connector Connector for connecting the optional warning light unit, PL02-TOS. p.17 , p.69
4
AC LINE connector AC inlet. p.21
5
Serial number This is the serial number of the TOS5300 Series. —
6
Chassis terminal Terminal for grounding the product when it cannot be grounded through
the power cord.
—
SIGNAL
I/O
COM
STATUS
OUT
+
STRIP-GAUGE
AWG
24-16
10 m m
AC INPUT
50/60Hz
800VA MAX
10 0
-
240V
KIKUSUI ELECTRONICS CORP.
MADE IN TAIWAN
ᮏ〇ရ䛾䜹䝞䞊䛿䚸⤯ᑐ䛻ྲྀ䜚እ䛧䛶䛿䛔䛡䜎䛫䜣䚹
ෆ㒊䛾Ⅼ᳨䛿ᙜ♫䛜ㄆ䜑䛯䝃䞊䝡䝇䝬䞁䛻ጤク䛧䛶䛟䛰䛥䛔䚹
୺㟁※䝁䞊䝗ཬ䜃㈇Ⲵ⥺䛾ྲྀ䜚ᢅ䛔䛿䚸ᚲ䛪୺㟁※䝥䝷䜾䜢ᢤ䛔䛶
䛛䜙⾜䛳䛶䛟䛰䛥䛔䚹
DO NOT REMOVE COVERS. NO OPERATOR SERVICEABLE
PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
UNPLUG THE MAINS SUPPLY CORD BEFORE HANDLING
THE CORD OR LOAD WIRES.
WARNING
㆙࿌
10
1 2
4
6
3
5
See
