Sensoface messages can be assigned to a relay contact:
Parameter Setting

Inputs and Outputs

Relay Contacts

Contact K…

Usage
If you select Sensoface , all Sensoface messages are output via the selected contact.
If you select Sensoface (Channel) , you can output the Sensoface messages from a specific channel via
the selected contact.
Sensoface Criteria
Conductivity (Contacting)
Sensoface Cell constant
2-/4-electrode sensors Memosens
Happy 0.005 cm
-1
… 19.9999 cm
-1
0.5x nom. cell constant … 2x nom. cell constant
Sad < 0.005 cm
-1
or
> 19.9999 cm
-1
< 0.5x nom. cell constant or
> 2x nom. cell constant
Conductivity (Inductive)
Sensoface Cell factor Zero point
Analog sensors Memosens
Happy 0.1cm
-1
… 19.9999cm
-1
0.5 x nom. cell factor … 2 x nom. cell
factor
-0.25mS … 0.25mS
Sad < 0.1cm
-1
or
> 19.9999cm
-1
< 0.5x nom. cell factor or
> 2x nom. cell factor
< -0.25mS or
> 0.25mS
Note: The worsening of a Sensoface criterion leads to the devaluation of the Sensoface indicator
(Smiley gets "sad"). An improvement of the Sensoface indicator can only take place after calibration or
removal of the sensor defect.
Sensocheck
Process variable Sensocheck function
pH Automatic monitoring of glass and reference electrode
Oxygen Monitoring membrane/electrolyte
Conductivity Information on sensor condition
Enable/Disable Sensocheck
Sensocheck is enabled and disabled in the Sensor Data submenu:
With Memosens:
Parameter Setting

[I] [II] Memosens …

Sensor Data

Sensor Monitoring Details

Sensocheck
You can enable or disable Sensocheck in the Monitoring menu item.
In the Message menu item, select whether a Sensocheck message is output as a failure or
maintenance required message.
With analog sensors:
Parameter Setting

[I] [II] [Sensor]

Sensor Data

Sensocheck
In the Sensocheck menu item, you can disable Sensocheck or choose to output a Sensocheck
message as a failure or maintenance required message.
