4.5 Operating States
While the parameters are being set, Stratos Multi is in the function check (HOLD) mode. The current
output and relay contacts behave in accordance with the parameter settings. In the function check
(HOLD) mode, measurement is not permitted since unexpected system behavior might put users at
risk.
Operating Mode Current
Outputs
Contacts Controller
(PID Controller)
Timeout
1)
Measuring -
Diagnostics -
Calibration
2)
-
Maintenance
2)
Sensor Monitor -
Current Source -
Manual Controller -
Parameter Setting
2)
20 min
Rinse Function
2)
3)
At end of rinse time
Active (output functions normally) Manual control of the outputs
Last value or fixed default value Depending on parameter setting
4.6 Measurement Display
The following settings are possible:
2, 4, 6, or 8 values
without measuring channel selection
Any display of measured values from the measuring channels
and the device possible
2 or 4 values with measuring channel selection Any display of measured values from the measuring channels
Settings can be changed in the Measurement Display submenu:
Parameter Setting

General

Measurement Display
An overview of display options can be found in the Parameter Setting chapter.
➜
Parameter Setting, General, p. 48
The right softkey: Back to Meas. returns you to measurements from any menu level. You may have to
confirm that the system is ready for measurement.
If required, the display can be configured to switch off after not having been used for a user-defined
period of time.
This setting can be changed in the Display submenu:
Parameter Setting

General

Display
Display auto-off can be configured as follows:
• No auto-off
• After 5 minutes
• After 30 minutes
1)
“Timeout” means that the device will return to measuring mode after 20 minutes without key activity.
2)
Function check (HOLD) is active.
3)
Rinse contact is active.
