12.3 Device
Product name
Stratos Multi
Product type
E401N
Measurements
pH
ORP
Amperometric oxygen/optical oxygen
Contacting/inductive conductivity
Dual conductivity
2 parameter sets
Parameter set A and B
Select via digital control input OK1 or manually
Memory card
Accessories for add-on functions in hazardous and safe areas
(firmware update, measurement recorder, logbook)
Memory size 32MB
Logbook For exclusive use: min. 20,000 entries
Measurement recorder For exclusive use: min. 20,000 entries
Connection to PC Micro USB
Connection to device Plug
Communication USB2.0, high-speed, 12Mbit/s
Data Card, MSD (Mass Storage Device)
FW Update Card, FW Repair Card: HID (human interface device)
Dimensions L 32mm x W 12mm x H 30mm
Display
Graphical TFT color display, 4.3″, white backlighting
Resolution 480x272pixels
Language German, English, French, Spanish, Italian, Portuguese, Chinese
Sensoface Sensor status display: Happy, neutral, sad smileys
Status indicators Icons for parameter setting and messages
Keypad
Softkey 1 left, softkey 2 right, arrow keys (cursor), enter
Door contact
When front open: electrical signal and logbook entry
Real-time clock
Different time and date formats selectable, power reserve approx. 1 day
Housing
Molded housing Glass fiber reinforced
Front unit material: PBT
Rear unit material: PC
Ingress protection IP66/IP67 / NEMA4XOutdoor (with pressure compensation) provided the
housing is closed
Flammability UL 94V-0 for external parts
Weight 1.2kg (1.6kg incl. accessories and packaging)
Mounting Wall, pipe/post or panel mounting
Color Gray RAL 7001
Dimensions H 148mm, W 148mm, D 117mm
Control panel cutout 138mm x 138mm acc. to DIN 43 700
Cable glands
5 knockouts for M20 x 1.5 cable glands
2 of 5 knockouts for NPT ½″ or rigid metallic conduit
Terminals, screw terminals
Power supply, sensor, current outputs, current input, relay contacts, digital control inputs
Single or stranded wires up to 2.5mm²
Tightening torque min. 0.5Nm/max. 0.6Nm
Spacing 5mm
