Stratos Multi E401N

Module for Dual Conductivity Measurement

Order code MK-CC065N

Memosens Module

Order code MK-MS095N

3.5 Final Check During Commissioning

Only commission the Stratos Multi if all the questions below can be answered “yes”:

• Are the Stratos Multi and all its cables externally intact and strain-relieved?

• Are the cables routed without any loops or crossovers?

• Have all the wires been correctly connected in accordance with their terminal assignments?

• Was the tightening torque of the screw terminals correctly adhered to?

• Are all connectors firmly engaged?

• Are all cable glands installed, tight, and leak-proof?

• Is the device closed and correctly screwed together?

• Does the supply voltage (power supply) accord with the voltage indicated on the nameplate?
