Knick Stratos Multi E401N - Pipe Mounting ZU0274

Stratos Multi E401N
23
3.1.3 Pipe Mounting ZU0274
Note: All dimensions are given in millimeters [inches].
Ø 40… 60mm, □ 30… 45mm
40 [1.57] ... 60 [2.36]
1
2
1
2
3
3
4
4
1
For vertical or horizontal posts or pipes
3
Hose clamp with worm gear drive according to
DIN 3017, 2x
2
Pipe-mount plate, 1x
4
Self-tapping screw, 4x
