8 Maintenance
Menu Selection
Back
Maintenance
Lingua
Note: Function check (HOLD) is active. The current output and relay contacts behave in accordance
with the parameter settings. Return to measuring mode to exit the function check, e.g., with the right
softkey: Back to Meas.
8.1 Overview of Maintenance Functions
Maintenance
Back
Memosens Oxy
Back to Meas.
Analog Cond-Cond
II
Cond, Cond Calculation
Current Source
Relay Test
I
CI
Controller Test
The Maintenance menu provides various functions for checking the device function:
Submenus
Open/Close Memory Card
Only if Data Card is inserted ➜ Memory Card, p. 153
[I] [II] [Sensor] Depending on sensor type, e.g.: sensor monitor
➜
Channel I/II Maintenance Functions, p. 134
[CI] [CII] Cond, Cond
Calculation
When using the Cond/Cond calculation block to calculate pH value upstream and
downstream of an ion exchanger: Confirm ion exchanger replacement.
➜
Calculation Blocks (FW-E020), p. 206
Current Source
Function test: manual control of current outputs in full range ➜ Current Source, p. 134
Relay Test
Function test of relay contacts ➜ Relay Test, p. 134
Controller Test Function test: manual control of the PID controller (if configured)
➜
Controller Test, p. 134
