Knick Stratos Multi E401N - pH Analog Wiring Examples

Stratos Multi E401N
168
13.1 Channel II Wiring Examples
13.1.1 pH Analog Wiring Examples
Example 1, pH Analog
Measuring task: pH, temperature, glass impedance
Sensors (example): SE 555X/1-NS8N
Cable (example): ZU0318
3
1 2
4
5
6
1
Core
4
pH Module
2
Shield
5
Cables
3
Jumper!
6
Sensors
