Knick Stratos Multi E401N - Dimension Drawings

Stratos Multi E401N
21
3.1.1 Dimension Drawings
Note: All dimensions are given in millimeters [inches].
80 [3.15]
34 [1.34]
7
4
[
2
.9
1
]
121,4 [4.78]
1
0
6
,
4
[
4
.1
9
]
9
0
[
3
.5
4
]
90 [3.54]
131 [5.16]
2
0
,
3
[
0
.8
0
]
2
9
[
1
.1
4
]
3
6
[
1
.
4
2
]
1
3
7
,
6
[
5
.
4
2
]
42 [1.65]
42 [1.65]
2
2
[
0
.8
7
]
148 [5.83]
1
4
8
[
5
.
8
3
]
115,5 [4.55]
39,5 [1.56]
8,5 [0.33]
29 [1.14]
3
1
2
CAUTION! Ensure the suitable
IP protection.
IP66/IP67 is only achieved with correctly
installed cable glands.
Front View
Rear View
Bottom View
Side View
4
1
Holes for pipe mounting, 4x
3
Holes for cable glands or
½” conduit, ø21.5mm, 2x
2
Holes for wall mounting, 2x
Sealing with plastic sealing plugs
4
Cable glands, 5x
See also
➜ Blanking Plugs, Reduction Sealing Inserts, Multiple Sealing Inserts, p. 26
