13.1.4 Inductive Conductivity Wiring Examples
Example 1, Condl
Measuring task: Inductive conductivity/temperature
Sensors: SE655 or SE656
B C D E F G H
A
receive hi receive lo send lo send hi RTD RTD (sense) RTD (GND) shield
1
2 5 6 7 8
3 4
9
10
1
Blue
6
White
2
Red
7
Yellow
3
Coax red
8
Shield green/yellow
4
Coax white
9
CondI Module
5
Green
10
Cables
