Knick Stratos Multi E401N - Page 181

Stratos Multi E401N
181
Example 7, Cond
Measuring task: Conductivity, temperature
Sensors (example): 4-electrode fringe-field sensor, SE600/SE603
B C D E F G H
A
I hi U hi U lo I lo RTD RTD (sense) RTD (GND) shield
1
2 3 4
5
6 7 8 9
10
11
12
1
Gray
7
Yellow
2
Pink
8
Green
3
Blue
9
Shield yellow/green
4
Red
10
Cond Module
5
Brown, do not connect
11
Cables
6
White/green
12
Sensors
