5.7 Process Variable pH
Note: Function check (HOLD) is active.
Note: After changing the process variable or measuring mode, Stratos Multi retains its settings but
needs to be reconfigured.
Selecting a Memosens pH Sensor
Parameter Setting

Sensor Selection [I] [II]

Sensor Selection [I]
Selection of the Memosens pH sensor connected to the RS-485 interface (terminals 1 … 5):
Parameter: Auto or pH
Mode: Memosens
Functionality: pH, ISFET, or pH/ORP (depending on sensor type)
Selecting a Second Memosens pH Sensor
Parameter Setting

Sensor Selection [I] [II]

Sensor Selection [II]
Selection of a second Memosens pH sensor connected to the MK-MS 095N measuring module:
Module: MK-MS
Parameter: pH
Mode: Memosens
Functionality: pH, ISFET, or pH/ORP (depending on sensor type)
Adjustable parameters for Memosens pH sensors
Parameter Setting

[I] [II] Memosens pH
Input Filter Pulse Suppression Enable/disable suppression of interference pulses.
Sensor Data
➜
Sensor Data, p. 66
Sensoface Enable/disable display of Sensoface messages and icons.
Sensor Monitoring Details Option to enter individual limits for monitoring slope and
zero point.
Enable/disable Sensocheck sensor monitoring. Set whether
Sensocheck should generate failure or maintenance required
messages.
Option to enter individual values before a message is trig-
gered for response time, sensor wear, sensor operating time
and SIP counter; also CIP counter with pH/ORP sensors; also
operating point and leakage current with ISFET sensors.
Cal Presettings Presetting of calibration mode and corresponding parameters, configuration of drift check
and calibration timer. ➜
Calibration Presettings, p. 68
TC Process Medium
➜ Temperature Compensation of Process Medium, p. 69
ORP/rH Value With Memosens pH/ORP sensor:
Selection of reference electrode:
Ag/AgCl,KCl 1mol, Ag/AgCl,KCl 3mol, Hg,Tl/TlCl,KCl 3.5mol, Hg/Hg
2
SO
4
,K
2
SO
4
sat
Enable/disable ORP conversion to standard hydrogen electrode SHE.
Calculate rH with or without factor.
Delta Function Display deviations from a preset value (delta value):
Output value = measured value – delta value ➜
Delta Function, p. 70
Messages Enable/disable messages for the separate process variables, or specify individual limits.
➜
Messages, p. 71
