Stratos Multi E401N
65
Selecting an Analog pH Sensor
Parameter Setting

Sensor Selection [I] [II]

Sensor Selection [II]
Selection of a pH or pH/ORP sensor connected to the MK-MS 015N measuring module:
Module: MK-PH
Mode: Analog
Adjustable parameters for analog sensors
Parameter Setting

[II] Analog pH
Input Filter Pulse Suppression Enable/disable suppression of interference pulses.
Sensor Data
➜
Sensor Data, p. 66
Sensor Type and Sensoface Sensoface, temperature monitoring, and the details of sensor
monitoring can be set, depending on the sensor type.
Temperature Detection Select temperature probe, set measuring and calibration
temperature.
Sensor Monitoring Details Slope, zero point, set Sensocheck of reference and glass
electrodes, and select response time.
Cal Presettings Presetting of calibration mode and calibration timer with corresponding parameters.
➜
Calibration Presettings, p. 68
TC Process
Medium
➜ Temperature Compensation of Process Medium, p. 69
ORP/rH Value With pH/ORP sensor:
Selection of reference electrode.
Enable/disable ORP conversion to standard hydrogen electrode SHE.
Calculate rH with or without factor.
Delta Function Display deviations from a preset value (delta value):
Output value = measured value – delta value ➜
Delta Function, p. 70
Messages Enable/disable messages for the separate process variables, or specify individual limits.
➜
Messages, p. 71
