Stratos Multi E401N
46
5.3.3 Function Control
The following functions can be activated by softkey or optocoupler input OK1:
Input OK1:
• Parameter set selection
• Flow
• Function check
• Function check (channel)
Right softkey:
• Off
• Value rotation
• Parameter set selection
• Favorites menu
The selection can be changed in the Function Control submenu:
Parameter Setting

System Control

Function Control
5.3.4 Calculation Blocks (TAN Option FW-E020)
Calculation blocks convert existing process variables to new variables.
The menu is only shown if the TAN option is activated.
Parameter Setting

System Control

Calculation Blocks
See also
➜ Calculation Blocks (FW-E020), p. 206
5.3.5 Time/Date
The time and date in the installed real-time clock are required for:
• Controlling calibration and cleaning cycles
• Displaying the time on the display
• Assigning times to the calibration data in the sensor head on digital sensors
• Diagnostic functions; logbook entries are given a time stamp, for example
Note: No automatic switchover from winter to summer time.
Settings can be changed in the Time/Date submenu:
Parameter Setting

System Control

Time/Date
5.3.6 Measuring Point Description
You can enter a tag number and notes (e.g. date of last maintenance).
Parameter Setting

System Control

Meas.Point Description
Display of the tag number in the Diagnostics menu ➜ Measuring Point Description, p. 131
5.3.7 Firmware Update (TAN Option FW-E106)
The firmware update is carried out using TAN option FW-E106 and a FW Update Card.
➜
Firmware Update (FW-E106), p. 213
The menu is only shown if the TAN option is activated and the FW Update Card has been inserted.
Parameter Setting

System Control

Firmware Update
