Knick Stratos Multi E401N - Dual Conductivity Wiring Examples

Stratos Multi E401N
184
13.1.5 Dual Conductivity Wiring Examples
Example 1, Dual Conductivity
Measuring task: Dual conductivity, temperature
Sensors A, B: 2x 2-electrode conductivity sensors
1
2
3
1
MK-CC065N module
8
Sensors
2
2x cable
