Stratos Multi E401N
185
Example 2, Dual Conductivity
Measuring task: Dual conductivity, temperature
Sensors A, B: 2x SE604 2-electrode conductivity sensor
1 2 3
4 5
1 2 3
4 5
6
7
8
1
White/pink
5
Black
2
Brown/gray
6
MK-CC065N module
3
Yellow/red
7
2x ZU0645 cable
4
Green
8
Sensors
