Knick Stratos Multi E401N - Process Variable ORP

Stratos Multi E401N
72
5.8 Process Variable ORP
Note: Function check (HOLD) is active.
Note: After changing the process variable or measuring mode, Stratos Multi retains its settings but
needs to be reconfigured.
Selecting a Memosens ORP Sensor
Parameter Setting

Sensor Selection [I] [II]

Sensor Selection [I]
Selection of a Memosens ORP sensor connected to the RS-485 interface (terminals 1 … 5):
Parameter: Auto or pH
Mode: Memosens
Functionality: ORP
Selecting a Second Memosens ORP Sensor
Parameter Setting

Sensor Selection [I] [II]

Sensor Selection [II]
Selection of a second Memosens ORP sensor connected to the MK-MS 095N measuring module:
Module: MK-MS
Parameter: pH
Mode: Memosens
Functionality: ORP
Adjustable parameters for Memosens ORP sensors
Parameter Setting

[I] Memosens ORP
Input Filter Pulse Suppression Enable/disable suppression of interference pulses.
Sensor Data
➜
Sensor Data, p. 73
Sensoface Enable/disable display of Sensoface messages and icons.
Sensor Monitoring
Details
Option to enter individual limits for monitoring ORP offset.
Option to enter individual limits before a message for sensor
operating time and SIP counter is triggered.
Cal Presettings Presetting of the calibration mode; configuration of the calibration timer and ORP
check. ➜
Calibration Presettings, p. 74
ORP/rH Value Selection of reference electrode.
Enable/disable ORP conversion to standard hydrogen electrode SHE.
If using a pH sensor connected via a module at the same time: Calculate rH with or
without factor.
Delta Function Display deviations from a preset value (delta value):
Output value = measurement - delta value
Messages Enable/disable messages for the separate process variables, or specify individual limits.
➜
Messages, p. 75
Selecting an Analog ORP Sensor
Parameter Setting

Sensor Selection [I] [II]

Sensor Selection [II]
Selection of an ORP sensor connected to the MK-PH015N measuring module:
Module: MK-PH
Mode: Analog
When using an analog ORP sensor, the menus are the same as for an analog pH sensor:
Parameter Setting

[II] Analog pH
