Stratos Multi E401N
180
Example 6, Cond
Measuring task: Conductivity, temperature
Sensors (example): 2-electrode sensor SE630
B C D E F G HA
I hi U hi U lo I lo RTD RTD (sense) RTD (GND) shield
2 1 3
3
2
1
1
2 3 4 5 6 7 8
9
10
11
12
1
Brown
7
Pink
2
Yellow
8
Black, shield
3
Green
9
Cond Module
4
White
10
Cables
5
Gray
11
Sensors
6
Red
12
Sensor head connector
