Kohler KDI 2504TM

7
INFORMATION FOR DISASSEMBLY
EN 98
7.14.9 Crankshaft bushings
1.
Remove the crankshaft bushings AC from the uppe
r
s
emi-crankcase AB.
I
mportant
•
The crankshaft half-bearings AC are made of special
material. Therefore, they must be replaced every time
t
hey are removed to prevent seizures.
Fig 7.57
2.
Remove the crankshaft bushings AF from the lowe
r
cr
ankcase D.
Fig 7.58
7.14.10 Cover 3 at PTO ( )
1.
U
ndo the screws AG.
2.
Remove the cover AH and the gasket AL.
Fig 7.59
