Kongsberg Simrad EK80 - Installation requirements

394149/D
35
ItemPartnumberInthebox
Seriallinesplitter
337775
Seriallinesplitter(Øverland
UPC-5000P)
TheØverlandUPC-5000Pserialline
splitterofferstwoseparateinputsand
fteenRS-232andRS-422outputs.
Seriallinesplitter
317156
Seriallinesplitter(ØverlandUPC-3005)
TheØverlandUPC-3005serialline
splitteroffersoneinputandeight
RS-232andRS-422outputs.
Relatedtopics
Additionaloptionalitems,page31
Scopeofsupply,page25
SimradEK80,page13
Uninterruptiblepowersupply(UPS)
ItisimportanttoensurecontinuousoperationoftheEK80independentofvarying
qualityofthevessel'smainssupply.Theuseofanuninterruptiblepowersupplyis
thereforerecommended.
Uninterruptiblepowersupplyunitsarenot
includedinthestandardEK80delivery.
Theseitemsmustbepurchasedlocally.
Severalcommercialtypesareavailable.Tochoosethebestpowersolutionforyour
EK80installation,considerenvironmentalconditions,spaceavailable,theavailability
anddurationofthebatteries,andthepowerrequirementsoftheEK80.
Note
MakesurethattheUninterruptiblePowerSupply(UPS)doesnotgenerateswitching
noiseinthesamefrequencybandastheEK80.
Theminimumrequirementsfortheuninterruptiblepowersupply(UPS)are:
•Inputvoltage:Theinputvoltagemusttvesselsupplyvoltage.
•Outputvoltage:230V AC,50Hz
•Outputpower:TheoutputpowermustexceedtherequirementsoftheEK80.
•Outputform:TheoutputACvoltagemustbeasinewave.
Relatedtopics
Additionaloptionalitems,page31
Scopeofsupply,page25
SimradEK80,page13
Uninterruptiblepowersupply(UPS)requirements,page37
SimradEK80
