3-9
bizhub PRESS C71cf
3
G Press WEB GRIPPER1 and WEB GRIPPER2 on the control panel of Roll Winder
RW-101 to unlcock the media pressing bar 1 and media pressing bar 2.
H Close the media cover.
WEB
GRIPPER2
WEB
GRIPPER1
EMG.RESET
READY JOG
STOP
