4-19
4.2 Daily Cleaning
H Open the media cover of Roll Winder RW-201 and make sure that the media is
positioned 105 mm (±0.25 mm) / 4.13" (±0.01") away from the metal plate.
I Close the media cover of Roll Winder RW-201.
105 mm
