Appendix
page
103
Dosing unit/
Syringes
Occupat
ion
Dosing unit/
Syringes
Occupat
ion
DS3226
6 autom.
1 manual (m)
DS3227
7 autom.
1 manual (m)
DS3228
8 autom.
Carrying out
the ins
tallatio
n
1.
Use four hexagon socket screws to sc
rews the syringe revolver t
o the
attachment plate for the dosing uni
t.
For some dosing sys
tems, manual screws
are provided instead.
Attachment
plate
104
106
