page
108
Appendix
Proc
edu
re
1.
Open the doors of both compartments.
2.
Remove the covers from the illumination housin
g and the camera housi
ng.
In
order to do that, pu
ll
the spring inside the c
hamber and lift up the cover.
3.
Unscrew the upper cover from both sides (screw
s at the top of the left and right
chamber) and remove it.
109
111
